FEATURES

• Designed for measuring AC current, AC voltage and resistance.
• Top 1000A range designed for high level electrical engineering applications.
• Rotary scale which presents only one scale in the window at one time to avoid any possible reading errors.
• Pointer lock function freezes the reading in dimly lit or hard to reach places.
• Water-Drop Shape Core Jaws makes it easier to clamp the conductor in crowed environments.
• Ohm range ideal for checking the continuity of relays, transformers and motor coils.

SPECIFICATIONS
Ranges-.
ACA 10/30/100/300/1000 A
ACV 150/300/750V
Resistance 2 K W center reading at 20 W

Accuracy:
AC Current ±3% of full scale value
AC Voltage ±3% of full scale value
Resistance ±3% of full scale length

Insulation: AC 2,500V for one minute

Dimension: 227mm(L) x 73mm(W) x 33mm(D)

Weight: approx. 460g (battery Included)

Conductor size: approx. 52mm max.

Frequency response: 50/60 Hz

Accessory, operational manual, test lead, ohm test probe, carrying case, spare fuse.
