FEATURES

• Battery Operated.
• Solid state circuitry
• Battery check feature.
• Automatic circuit discharge
• Color coded scale
• Three megohm voltages
• Alternating voltage measurement
• Fuse protected
• IEC 1010 CAT III

SPECIFICATIONS:

Insulation resistance ranges
0-100 MW (+250 V DC+10%)
0-200MW (+500 V DC + 10%)
0-400MW (+1000 V DC + 10%)

Accuracy: +5% of indicated value (approx.)

Short circuit terminal current: 2mA

Power consumption:

• Max. consumption current approximately 120 mA

AC Voltage:

• Range: 0-600V
• Accuracy: +2.5% of full scale
• Line frequency range:40~1 KHz

Continuity

• Ohm range: 0~50W & infinity
• Accuracy: +-5% of indicated value (approx.)
• Open circuit terminal voltage: +600 DC mV (approx.)
• Short circuit terminal current: 240 DC mA (approx.)

Power consumption:
Max. consumption current approximately 120 mA

Withstand voltage: Meets IEC-l010 Category Ill. ·

Dimensions: 170 x165 x 92mm (6.7x6.5x3.6 inch), with housing front cover. ·

Weight: Approx. 970g (battery included).

Standard accessories:

• Batteries: AA 1.5V x8
• Test Leads x 1 pair
• Fuse lA, 250V x 1
• Instruction Manual x 1
