1. Control element:Samsung ARM7 CPU, 32Bits, 33 MHz
2. Memory:128K x 8 Flash (128 KB) 1M x 16 DRAM (2 MB)
3. Network:
     Communications interface: RJ-45 Connector
     Transmission rate:10/100 Mbps
     Communications protocol: ARP, IP, ICMP, UDP, TCP, HTTP, DHCP
     Online model: TCP Server/Client,UDP Client
     Network settings: HTTP browser settings (IE & Netscape)
     Network security: Set passwords and online passwords management
4. Serial port:
     Communications interface: RS232 / 422 / 485
     Transmission rate: 300bps - 115.2kbps
     Parity check: None, Odd, Even
     Data bits: 7, 8
     Stop bits: 1, 2
5. Possesses Watch Dog function
6. Software can be updated online via the Internet
7. Power source: DC 9-12 V , 500mA
